034 Motorsport Sway Bar Front End Link Pair Audi A3/S3/RS3 8V/VW Golf 8R

034 Motorsport Sway Bar Front Adjustable End Link Pair Audi A3/S3/RS3 8V/VW Golf 8R MQB, and MQB EVO

Replace your flimsy, imprecise OEM sway bar end links with these performance engineered adjustable spherical endlinks from 034Motorsport! Designed to improve handling, road feel, and steering response, 034Motorsport's Billet Adjustable Front Sway Bar End Links allow for uncompromised transfer of suspension movement to the sway bar. These end link are also length adjustable to allow for lowered vehicles to maintain proper preload on the sway bar.

Please Note: For lowered vehicles, always check all clearances over the full articulation of the suspension in order to identify possible interference. We recommend running 034Motorsport suspension components, as they have been designed and tested to work together, without interference.

What is Sway Bar Preload?

When a sway bar is preloaded, it means that it is already twisted when the car is at rest, and it’s trying to roll the car to one side because of this. This will lead to asymmetric behaviour and the car will favor tuning one way versus the other.

Preload is detectable when the car is at ride-height on a flat surface, and removal of an end link is difficult because the sway bar is already twisted and applying force on the bolt, or installing the endlink is difficult because the bar needs to be twisted to insert the bolt through the hole in the sway bar. With equal-length non-adjustable sway bar end links, removing preload is not possible.

By utilizing our 034Motorsport adjustable end links, the lengths of each endlink can be adjusted so that the endlink can be easily installed at ride-height without needing to twist the bar to get it to fit. Zero preload provides symmetrical handling in right and left turns.

Features:

• CNC Machined 6061-T6 Aluminum Bodies (Anodized Black for Durability)
• CNC Machined Steel Adapter Hardware (Zinc Plated for Durability)
• Motorsport Quality Aurora Spherical Bearings Featuring Self-Lubricating Teflon Race Lining
• High Misalignment Sphericals - Allow Proper Articulation Without Binding
• +/- 0.75" of Adjustability (1.5" Total Adjustment Range)
• Sold In Pairs

Functions:

• Adjust Sway Bar Preload - Essential When Corner Balancing Lowered Vehicles
• Improved Sway Bar Reaction Time & Accuracy

Recommended Alignment:

034Motorsport RS3 track use alignment specs; these specifications are optimal for a track driven car with a very "loose" handling attitude and lively rear end that drives towards oversteer. Caution should be used with these alignment specs as they can cause the car to over-rotate and spin, especially during throttle-lift conditions while turning:

• Front: (Tires: 265/35-18 Michelin Sport Cup 2)
  • Camber: -3.0 degrees each side (034-601-1013 camber mounts)
  • Caster: 7.1 degrees (not adjustable)
  • Toe: 0.6mm (toe-in) each side

• Rear: (Tires: 245/40-18 Michelin Sport Cup 2)
  • Camber: -1.5 degrees each side
  • Toe: 0.8mm (toe-in) each side

Our test vehicle is also running 034Motorsport front and rear sway bars, and all 034Motorsport spherical Motorsport line of products.

Audi A3 8V 1.8 TFSI
Audi A3 8V 2.0 TFSI

Audi A3 8Y 2.0 TSI
Audi S3 8V 2.0 TFSI

Audi S3 8Y 2.0 TSI
Audi TT 8S 2.0 TFSI
Audi TTS 8S 2.0 TFSI

Audi RS3 8V / 8.5V 2.5 TFSI

Audi TTRS 8S 2.5 TFSI

Audi A3 8P 1.8 TFSI
Audi A3 8P 2.0 TFSI
Audi A3 8P 2.0 TDI
Audi S3 8P 2.0 TFSI
Audi TT 8J 2.0 TFSI
Audi TT 8J 2.0 TDI
Audi TTS 8J 2.0 TFSI

Audi TTRS 8J 2.5 TFSI

Audi RS3 8P 2.5 TFSI

Volkswagen Golf 5 R32

Volkswagen Golf 5 GTI

Volkswagen Golf 5 GTI Ed30

Volkswagen Golf 6 GTI

Volkswagen Golf 6 R

Volkswagen Golf 7 GTI
Volkswagen Golf 7 R

Volkswagen Golf 8 GTI
Volkswagen Golf 8 R

Volkswagen Passat B6 1.8 TSI
Volkswagen Passat B6 2.0 TSI

Volkswagen Passat B7 1.8 TSI

Volkswagen Passat B7 2.0 TSI

Volkswagen Passat B6 2.0 TDI
Volkswagen Passat B6 1.8 TSI

Volkswagen Tiguan AD/BW R
